HJA410155N10K1500T Exploded Chart Parts Details
Summary description:
key word:
Category:
- 零件清单
- Description
- Linked Parts List
-
Serial Number Specifications Name Quantity Remarks 1 HJ28-02J-2801H/466 Front Bracket Welding Assembly 2 2 HJ28-02-2801-03 Side plate 8 3 HJ28-02-2801-04/ZM Leaf spring cushion block 4 4 HJ29-02-2901-06 Spacer sleeve 16 5 GB/T5782-2000 M20x165 Bolt-M20 * 165 20 6 GB/T6182-2000 M20 Nylon self-locking nut-M20 20 7 GB/T5782-2000 M14x160 Bolt-M14 * 160 16 8 GB/T6182-2000 M14 Nylon self-locking nut-M14 32 9 HJ28-02J-2802DH/70L
HJ28-02J-2802DH/70RMiddle bracket welding assembly (left)
Middle Bracket Welding Assembly (Right)3
32 left and 2 right pieces respectively;
Left10 HJ29-02J-2904H/zj70 Balance beam welding assembly 6 11 HJ29-02-2904/70-05F Bushing 12 12 HJ29-02J-2904-06H Side Plate Intermediate Sleeve Welding Assembly 12 13 HJ29-02-2904/70-09 Gasket 12 14 HJ-860201B-005-01 Balance beam pin 6 15 HJ29-02-2904-11-2 Balance beam pin washer 6 16 HJ29-02-2904-11-3 Balance Beam Pin Nut 6 17 JB/T7940.1-1995 M10X1 Straight grease nipple M10X1 6 18 HJ28-02J-2803H/315 Rear Bracket Welding Assembly 2 19 HJBH-BO-1310.10.20.100 leaf spring 8 20 HJ29F-02-4801X(Z)M Upper splint 8 21 HJ29-02-2910 Torsion base 8 22 HJ29F-02-4805/ZG briquette 8 23 HJ29F-02-4804X/480-01 U-bolt 16 24 HJ29-02-2907-02 U-bolt nut 64 25 HJ29-02-2901-05-2 Stamping self-locking nut-M36 16 26 HJ29-02-2911-01 Bolt-M36 * 156 8 27 HJ29-02-2901-05-1 Bolt-M36 * 186 2 28 HJ29-02-2902-07-1 Bolt-M36 * 214 6 29 HJ16-0509 Pull rod damping sleeve 16 30 HJ28-02-2806H/475 Fixed Pull Rod Weld Assembly -475 1 31 HJ28-02-2806H/510 Fixed Pull Rod Weld Assembly -510 3 32 HJ29-02-2906-01 Fitting-Left 4 33 HJ29-02-2906-02 Fitting-Right 4 34 GB/T5782-2000 M14x70 Bolt-M14 * 70 16 35 HJ29-02-2906-03/330 lead screw -330 1 36 HJ29-02-2906-03/370 lead screw -370 3
